CSP 256LED strip light

Model NO.: HT-CCCW256-10W-12/24V-8F0

CRI: >90
Lumen: 920lm/M
Power: 10W/M
Input Voltage: 12V/24V DC
PCB width: 8mm
Beam Angle: 140 degree
IP rate: IP20/IP65

Quantity:

Product Description

Product Features：

Latest technology CSP chips adopted, which the area of the chip almost the same as the encapsulated area
Small volume of the chip with good heat dissipation
Provide excellent texture appearance of the object
Linear lighting, without light spot, soft and uniform luminance
Application in museum, jewellery exhibition, leather goods show and so on

Parameters:

CCT	CRI	Luminous Flux(lm/m)	Luminous Efficacy(lm/w)	Power	Width	Voltage	Mini cut
2700K	>90	780lm/m	78lm/w	10W/M	8mm	12V/24V DC	31.5mm/62.5mm
3000K		830lm/m	83lm/w
6500K		920lm/m	92lm/w
